Item number 152265
Container standards DIN 30722 SIS3021 SS3659, Hook height 1450 mm - 1570 mm
Container lengths 4000mm - 4500 mm
Axles: one-piece axel body 110x110, Flange width 1 800 mm
Load: 8 ton at 62 km/h, laser aligned
Coated according KTL-method, black
Axle distance 1 190mm (16 tons), Axle system: Road
Rim connection 280x335x8, domed nuts
Communicating vessels: The chassis height is adjustable (from driver´s seat) 350mm
Hydraulic brakes on all drums. Size 410x120. According VVFS 2003:20
Automatically adjusted brake arms AGS.
Cover sheets stop dirt entering the brake drums.
Hydraulic outlets needed on tractor: 3 DA + free return+ brakes, el. system 12 Volt
Tipping power 14 tons, Tipping angle 48º,Oil volume needed while tipping 16 liters
Shifting power 12 tons, maximum angle 28º, Oil volume needed while tipping 3 liters
Oil volume need from tractor: 16 L/210 Bar, Oil tank in tractor min.19L
Lights according TSV LED 12-24V 7 pol.
Hydraulic switching between shifting and tipping
Prepared console for mounting different drawbars
Prepared console for mounting a hydraulic rear supporting bar
Colour Metsjö grey
Chassis weight 2 300 kg, Technical load 19 000 kg, Payload 16 700 kg
Surface treatment: chemical degreasing, blasting SA 2,5
The body is puttied. The colour of the chassis is grey
Painting according ISO 12944 A3.09. Colour system: Epoxy primer 2 x 70 µm.
Top coat: Polyurethane 1 x 60 µm overall layer 200µm. Corrosion category C4 L
Equipped with:
Hydraulic socket DA on the hook-lift arm, 129935
