Olympia 95 chassis 385/65x22,5

Item number chassis: 166713 Axles: one-piece axel body 120x120, Flange width 2 000 mm Load: 10,5 ton at 62 km/h, laser aligned Coated according KTL-method, black Axle distance 1 305mm, Axle system: Road Rim connection 280x335x10, domed nuts Communicating vessels: The chassis height is adjustable (from the chassis) 350mm Hydraulic brakes on all drums. Size 410x120. According VVFS 2003:20 Automatically adjusted brake arms AGS. Maximum hydraulic pressure 110 bar Cover sheets stop dirt entering the brake drums Back tipping, Tipping angle 52, Oil volume 45L/210 bars, Electrical system 12 Volt Lights according TSV LED 12-24V 7 pol. Prepared console for mounting different drawbars Colour Metsjö grey Chassis weight: 4 600 kg, Technical load: 42 000 kg, Payload 37 400 kg Surface treatment: chemical degreasing, blasting SA 2,5 The body is puttied. Painting according ISO 12944 A3.09. Colour system: Epoxy primer 2 x 70 µm. Top coat: Polyurethane 1 x 60 µm overall layer 200µm. Corrosion category C4 L
