Item number 174360
Container standards DIN 30722 SIS3021 SS3659, Hook height 1450 mm - 1570 mm
Container lengths 5000mm-6500mm. Adjustable load on the drawbar
Distance drawbar/steering point 1488mm, Steering angle 40"
Double-acting hydraulic function with a hydraulic lock
Tracks: Camso TTS 80
Payload 36 000 kg
Total outer width 2862mm, Trace width 2100mm
Width 762mm Track length 3450mm (distance rollers 2830mm)
Height 900mm/1013mm
40km/h
Hinged in the middle
Without brakes
Tracks weight 4 500kg
Hydraulic outlets needed on tractor: 4 DA + brakes, el. system 12 Volt
shifting valve between tipping/shifting, prolonging the hook-lift arm/double acting rear outlet,
rear ground support, frame steering
Tipping power 22 tons, Tipping angle 52º,Oil volume needed while tipping 29 liters
Shifting power 22 tons, Oil volume needed while shifting 18 liters
Oil volume need from tractor: 29 L/210 Bar, Oil tank in tractor min.47L
Lights according TSV LED 12-24V 7 pol.
Hydraulic switching between shifting and tipping
Hydraulic rear ground support
Hydraulic rear socket double-acting
Prepared console for mounting different drawbars
Prepared console for mounting a hydraulic system for switching between shifting and tipping
Prepared console for mounting hydraulic locking of the container
Colour Metsjö grey
Chassis weight 7 500 kg, Technical load 39 000 kg, Payload 31 500 kg
Surface treatment: chemical degreasing, blasting SA 2,5
The body is puttied. The colour of the chassis is grey
Painting according ISO 12944 A3.09. Colour system: Epoxy primer 2 x 70 µm.
Top coat: Polyurethane 1 x 60 µm overall layer 200µm. Corrosion category C4 L
