Item number chassis: 104380
Pendulum bogie distance 1050 mm, Maximum load 4,5 tons per axle
Flange width 1850 mm. Coated according to KTL-method, black
Rim connection 161x205x6 open nuts
Hydraulic brakes: on all drums, According VVFS 2003:20
Manually adjusted brake arms. Maximum hydraulic pressure 110 bar
Cover sheets stop dirt entering the brake drums
Back tipping, tipping angle 55º, Oil volume 10L /210 bars
Lights according TSV LED 12-24V 7 pol.
Prepared console for mounting different drawbars
Colour Metsjö grey
Prepared for MetaMid/MetaNo bodies
Chassis weight 1 450 kg, Technical load 12 000 kg
Item number container: 110336
Container with drop-down sides Mid/No L4165 H450 W2550 4,6m3
Steel 355 Brinell: Container bed 4 mm and sides 3 mm
Manuall tailgate H600 mm "Multi-hinged" top pivoted/foldable downwards
Drop-down sides, Height 450mm, Length per section 2 000mm
2 hinge fittings and 2 locks per section
Front wall height 600mm
Stabilising bar between the side panels
Hooks for load securing 1,5 tons outside 6pcs. per side
Consols for mounting supporting legs on the containers
Colour red, painted according Metsjö standards
Fits on MetaMid and MetaNo chassis
Weight 1050 kg
Weight of the trailer 2500 kg, Payload 9 500 kg
Surface treatment: chemical degreasing, blasting SA 2,5
The body is puttied.
Painting according ISO 12944 A3.09. Colour system: Epoxy primer 2 x 70 µm.
Top coat: Polyurethane 1 x 60 µm overall layer 200µm. Corrosion category C4 L
